Pillar drill SB510V 400V
Gegarandeerd Veilig afrekenen
| Artikelnummer | WF-951429 |
| Merk | Holzmann |
Recensies
Er zijn nog geen recensies — wees de eerste
Deel je ervaring met deze aankoop en help andere klanten de juiste keuze te maken
Vragen
Er zijn nog geen vragen
Stel een vraag om meer te weten te komen over het product
0.0
0 reviews
- Variable speed setting via frequency converter and LCD display
- Solid base plate for good stability
- Bending-resistant drilling column with ground surface
- Work table height-adjustable via rack and pinion
- Practical three-arm lever with drilling depth scale
- Foldable keyless chuck cover made of Plexiglas
- Drilling depth stop
- Thread cutting mode
Technical data
- Motor power S1 in W: 1100
- Voltage: 400V / 3 / 50Hz
- Protection class: IP22
- Cable length: 1.8 m
- Max. Drilling capacity in mm: ø32
- Thread size: max. M14
- Drill spindle mount: MK4 / MT4
- Drill spindle speed in min-1 (I): 80-600; (II): 80-2100
- Max. distance spindle to table in mm: 815
- Distance spindle to base plate in mm: 1160
- Column diameter in mm: 98
- Spindle stroke in mm: 135
- Base plate in mm: 650 x 440
- Max. Table load in kg: 60
Dimensions
- Installation dimensions in mm: 830 x 550 x 1770
- Throat in mm: 245
- Table size in mm: 410 x 380
Weight
- Net weight 201 kg
Scope of delivery
- Billboard drill SB510V 400V
- Keyless chuck 1-16mm B16
| External dimensions | |
|---|---|
| External dimensions | 830 x 470 x 1770 |
| Table size | |
| Table size | 410 x 380 mm |
| Projection | |
| Projection | 245 mm |
| Chuck width | |
| Chuck width | 16 mm |
| Power output | |
| Power output | 1,000 W |
| No-load speed | |
| No-load speed | 80 - 2,100 rpm |
| Colors | |
| Colors | red |
| Colors | silver |
| Noise level | |
| Noise level | 88.1 |
| Chuck type | |
| Chuck type | keyless chuck |
| Number of gears | |
| Number of gears | 2 |
| Drilling capacity in steel | |
| Drilling capacity in steel | 32 mm |
| Voltage | |
| Voltage | 400 V |
| Cable length | |
| Cable length | 1.8 m |
| IP protection class | |
| IP protection class | IP22 |
| Carrying case | |
| Carrying case | no |
| Weight | |
| Weight | 201 kg |
| Right-left rotation | |
| Right-left rotation | true |
| Drive | |
| Drive | 380 V motor |
| Spindle stroke | |
| Spindle stroke | 135 mm |
