Hauswasserwerk HWW 900/25
Gegarandeerd Veilig afrekenen
| Artikelnummer | WF-912183 |
| Merk | T.I.P. |
Recensies
Er zijn nog geen recensies — wees de eerste
Deel je ervaring met deze aankoop en help andere klanten de juiste keuze te maken
Vragen
Er zijn nog geen vragen
Stel een vraag om meer te weten te komen over het product
0.0
0 reviews
- Self-priming, powerful 600-watt pump with jet hydraulic system and thermal overload protection
- Very robust and smooth-running pump housing made of solid cast iron
- Pumps clear water at a constant pressure
- For automatic domestic water supply with domestic water from wells and cisterns, for garden irrigation and automatic sprinkling
- Ideally suited for pressure boosting through installation into the existing water network
With its particularly robust technology and features, the HWW 900/25 is a proven product in the field of domestic waterworks. The heavy cast iron pump housing guarantees exceptionally smooth, quiet, and efficient operation. It can be used to operate an sprinkler or as a pressure booster system.
Technical Data
- Rated power: 600 watts
- Maximum flow rate: 2,800 l/h
- Maximum discharge head / pressure: 42 m / 4.2 bar
- Maximum suction head: 9 m
- Pump housing: Cast iron
- Pressure vessel / volume: Steel / 18 l
- Discharge connection: 30.93 mm (1" IG)
- Suction connection: 30.93 mm (1" IG)
- Maximum temperature: 35 °C
- Connection cable: 1.5 m / H07RN-F
Dimensions
- Width: 48.5 cm
- Depth: 29.0 m
- Height: 50.0 cm
Weight: 13.9 kg
| Output | |
|---|---|
| Output | 600 |
| Material | |
| Material | Cast iron |
| Flow rate | |
| Flow rate | 2,800 l/h |
| Voltage | |
| Voltage | 230 V |
| Cable length | |
| Cable length | 1.5 m |
| Suction head | |
| Suction head | 9 m |
| Tank capacity | |
| Tank capacity | 18 l |
| Weight | |
| Weight | 13.9 kg |
| Cable | |
| Cable | H07RN-F |
| Drive | |
| Drive | 230 V motor |
| Maximum water temperature | |
| Maximum water temperature | 35 °C |
| Technical features | |
| Technical features | Thermal overload protection |
| Delivery head | |
| Delivery head | 42 m |
| External dimensions | |
| External dimensions | 48.5 x 29 x 50 cm x cm x cm |
| Connection size | |
| Connection size | 1 |
