Compact inverter welding machines for welding stick electrodes or for TIG welding (TIG hose package and pressure reducer optional). The set welding current can be read on the clearly visible LED display. Integrated automatic functions such as Hot Start, Arc Force, and Anti-Stick simplify work and improve the weld pattern. Robust and largely impact-resistant construction. Suitable for generator use.
Equipped with:
- LED display
- Forced cooling via integrated fan
- Thermal protection switch
- MMA-TIG switch
- Bayonet connectors
- Carrying strap
- Electrode holder with 1.5 m cable
- Ground clamp with 1.5 m cable
- Wire brush/ chipping hammer
A TIG hose package can be used optionally. The TIG process is particularly suitable for fine welding work, and can also be used to weld stainless steel, copper, or nickel.
Technical specifications:
- Mains voltage: 230 Volt +/-15% 50/60Hz
- Fuse protection: 16 amps
- Adjustment range: 20 – 165 amps
- Max. welding current at 30%: 165 amps
- Max. welding current at 60%: 140 amps
- Max. welding current at 100%: 105 amps
- Suitable for electrodes: 1.6 – 4.0 mm
- Protection class: IP21S
Dimensions: 310 mm x 115 mm x 190 mm
Weight: 4.7 kg
| Variants | |
|---|---|
| Variants | Inverter welder |
| Drive | |
| Drive | 230V motor |
| External dimensions | |
| External dimensions | 31 x 11.5 x 19 |
| Fuse | |
| Fuse | 16 A |
| Voltage | |
| Voltage | 230 volts |
| Cable length | |
| Cable length | 1.5 m |
| Welding current | |
| Welding current | 165 A |
| Weight | |
| Weight | 4.7 kg |
| Electrode thickness | |
| Electrode thickness | 1.6-4 mm |
