Tiefbrunnenpumpe AJ 4 Plus 100/57
| Artikelnummer | WF-863914 |
| Merk | T.I.P. |
Er zijn nog geen recensies — wees de eerste
Deel je ervaring met deze aankoop en help andere klanten de juiste keuze te makenEr zijn nog geen vragen
Stel een vraag om meer te weten te komen over het product
0.0
The more powerful model of the AJ series deep well pumps is characterized by its particularly high discharge head. The multi-stage hydraulic system of the AJ 4 Plus series deep well pumps is equipped with floating impellers, which are particularly resistant to the abrasive effects of sand up to a concentration of 50 g/m³.
The pressed ceramic ring in the diffuser and the graphite ring ensure high durability in the event of operation in water shortages. This deep well pump is equipped with an integrated check valve, a 20 m connection cable, and a drainage rope.
The small outer diameter of only 9.8 cm allows for use in narrow boreholes as small as 10 cm in diameter. It is used to pump water from great depths and to transport it at high pressure.
Technical data
- Motor: 1,100 watts
- Maximum delivery head / pressure: 57 m 5.7 bar
- Maximum delivery rate: 6,000 l/h
- Pump housing: stainless steel
- Maximum grain size: 2 mm / 50 g/m³
- Max. Immersion depth: 20 m
- Connection cable: 23 m H07RN8-F
- Max. medium temperature: 35°C
- Pressure connection: IG, 39.59 mm (1 1/4")
- MEI (Minimum Efficiency Index): greater than or equal to 0.40
| Solids size | |
|---|---|
| Solids size | 2 mm |
| Discharge head | |
| Discharge head | 57 m |
| Connection size | |
| Connection size | 1 1/4 |
| Material | |
| Material | Stainless steel |
| Output power | |
| Output power | 1,100 watts |
| Material | |
| Material | V2A stainless steel |
| Technical features | |
| Technical features | Check valve |
| Drive | |
| Drive | 230V motor |
| Maximum water temperature | |
| Maximum water temperature | 35°C |
| Immersion depth | |
| Immersion depth | 20 m |
| Maximum pressure | |
| Maximum pressure | 5.7 bar |
| Flow rate | |
| Flow rate | 6,000 l/h |
| Voltage | |
| Voltage | 230 volts |
| Cable length | |
| Cable length | 20 m |
